Model (2-stroke)
|
HMT30
|
|
Demension
|
Overall Length:843mm
Overall Width:399mm Overall Height S:1,146mm Overall Height L:1,273mm |
|
Net Weight
|
Short Shaft:53 kg Long Shaft:54.5 kg
|
|
Gross Weight
|
Short Shaft:63 kg Long Shaft:65 kg
|
|
Full Throttle Operating Range
|
4500-5500 r/m
|
|
Maximum Output
|
18.3 KW
|
|
Idling Speed
|
1100±50 r/m
|
|
Displacement
|
496 cc
|
|
Bore&Stroke
|
72*61mm
|
|
Ignition Systerm
|
CDI
|
|
Spark Plug
|
B7HS-10
|
|
Spark Plug Gap
|
0.9-1.0 mm
|
|
Control Systerm
|
Tiller Handle
|
|
Starting Systerm
|
Manual
|
|
Starting Carburetor Systerm
|
Choke Valve
|
|
Gear Position
|
Forward-Neutral-Reverse
|
|
Gear Transmission Ratio
|
2.08
|
|
Trim and Tilt Systerm
|
Manual Tilt
|
|
Recommended Fuel
|
Unlead Gasoline
|
|
Recommended Engine Oil
|
2-Stroke Outboard Motor Engine Oil
|
|
Gear Oil
|
0.320L
|
|
Fuel Tanks Capacity
|
24L
|
|
Fuel Oil Ratio
|
50:1
|
